V-serien videomiksere sammenligning
Roland har et bredt utvalg av videomiksere som støtter både HDMI og SDI-signaler. Noen har scaler på inngangene som gjør de mere egnet for signaler fra PC/Mac sammen med videokamera. Noen modeller har også innganger for for ekstern lyd i tillegg til lyden som er i videosignalet(embedded).
V-Series HD Video Switcher Comparison
 |
 |
 |
 |
 |
 |
 |
 |
 |
|
| Product Page | V-02HD MK II | V-1HD | V-1HD+ | V-1SDI | V-60HD | V-8HD | V-80HD | V-160HD | V-600UHD |
| Video Processing | 1080/60p | 1080/60p | 1080/60p | 1080/60p | 1080/60p | 1080/60p | 1080/60p | 1080/60p | 4K/60p |
| HDMI Video Input | 2 (2 x scalers) | 4 | 4 (1 x scaler) | 2 (1 x scaler) | 2 (2 x scalers) | 8 (2 x scalers) | 4 (4 x scalers including 2x 4K scalers) | 8 (4 x scalers) | 4 (4 x scalers) |
| HDMI Video Output | 2 | 2 | 2 | 1 | 3 | 3 | 3 | 3 | 4 |
| SDI Video Input | – | – | – | 3 | 4 | – | 4 | 8 | 2 (2 x scalers) |
| SDI Video Output | – | – | – | 2 | 2 | – | 2 | 3 | 1 |
| RGB/Component Video Input | – | – | – | – | 1 | – | – | – | 1 |
| Stream/Record USB to Computer |
✓USB 3.0 Up to 1080/60p |
– | – | – | – | – |
✓USB-C Up to 1080/60p |
✓USB-C Up to |
– |
| Stream/Record Directly from LAN | – | – | – | – | – | – |
✓(RTMP, SRT) |
– | – |
| Record Internally to SD Card |
– | – | – | – | – | – |
✓ |
– | – |
| Video/Audio Playback | – | – | – | – | – | – |
✓ |
– | – |
| Graphics Presenter Roland Fill+Key |
– | – | – | – | – |
✓Available in Q4 2024 |
✓Available in Q3 2024 |
✓Available in Q4 2024 |
– |
| Scene Memory Presets | 8 via app | 8 onboard & via RCS/app | 8 onboard & via app | 8 onboard & via RCS | 8 onboard & via RCS | 24 onboard & via app | 32 Memories, 100 Macros, & via app | 30 Memories, 100 Macros, & via app | 64 onboard |
| Analog Audio Input | Stereo Mini x 2 | RCA stereo x 1, Stereo Mini x 1 | RCA stereo x 1, Stereo Mini x 1, XLR x 2 | RCA stereo x 1, Stereo Mini x 1 | RCA stereo x 1, XLR/TRS x 4 | RCA stereo x 1 | RCA stereo x 1, XLR x 2 | RCA stereo x 1, XLR x 2 | XLR x 2 |
| Analog Audio Output | Phones x 1 | RCA stereo x 1, Phones x 1 | RCA stereo x 1, TRS stereo x 1, Phones x 1 | RCA stereo x 1, TRS stereo x 1, Phones x 1 | XLR Stereo x1, RCA Stereo x1, Phones x1 | RCA stereo x 1, Phones x 1 | XLR Stereo x1, Phones x 1 | RCA stereo x 1, XLR Stereo x1, Phones x 1 | XLR x 2, Phones x1 |
| Audio Mixer | 10 channels | 12 channels | 14 channels | 14 channels | 18 channels | 18 channels | 28 channels | 40 channels | 16 channels |
| PIP | 1 (variable zoom) | 1 (1/2, 1/3 or 1/4) | 1 (variable zoom) | 1 (1/2, 1/3 or 1/4) | 1 (1/2, 1/3 or 1/4) | 2 (variable zoom) | 2 (variable zoom) | 4 (variable zoom) | 2 (variable zoom) |
| Keyer Layers | 1 PIP (Luma, Chroma), 1 DSK (Luma, Chroma) | 1 DSK (Luma, Chroma) | 1 PIP (Luma, Chroma), 1 DSK (Luma, Chroma) | 1 DSK (Luma, Chroma) | 1 DSK (Luma, Chroma) | 2 PIP (Luma, Chroma), 1 DSK (Luma, Chroma, Alpha) | 2 PIP (Luma, Chroma), 1 DSK (Luma, Chroma, Alpha) | 4 PIP (Luma, Chroma), 2 DSK (Luma, Chroma, Alpha) | 2 PIP (Luma, Chroma) |
| Video Effects |
✓ |
✓ |
✓ |
✓ |
✓ |
✓ |
✓ |
✓ |
✓ |
| Audio Effects | 11 types | 7 types | 9 types | 7 types | 8 types | 8 types | 15 Types | 14 Types | – |
| AUX BUS | – | – | – | – | 1 | 1 | 2 | 3 | 1 |
| Still Image |
✓(1 Still) |
– |
✓(4 Stills) |
✓(1 Still) |
✓(2 Stills) |
✓(8 Stills) |
✓(32 Stills) |
✓(16 Stills) |
✓(8 Stills) |
| Capture Image |
✓ |
– |
✓ |
✓ |
✓ |
✓ |
✓ |
✓ |
✓ |
| Camera Battery Support |
✓ |
– |
✓ |
✓ |
✓ |
✓ |
– | – | – |
| PTZ Camera Control | – | – | – | – |
✓(6 Cameras) |
– |
✓(8 Cameras) |
✓(16 Cameras) |
✓(6 Cameras) |
| Remote Control | iPad RCS, PC RCS (Win/Mac), MIDI (USB) | iPad RCS, PC RCS (Win/Mac), MIDI (5-Pin/USB) | iPad RCS, RS-232 | PC RCS (Win/Mac), RS-232, MIDI (USB) | PC RCS (Win/Mac), LAN, RS-232 | iPad RCS, PC RCS (Win/Mac), MIDI (USB) | iPad RCS, PC RCS (Win/Mac), LAN, RS-232 | iPad RCS, PC RCS (Win/Mac), LAN, RS-232 | Web RCS, LAN, RS-232 |
| Footswitch Control | Single or double x 1 | – | – | – | – | Single or double x 2 | Single or Double x 2 | Single or double x 2 | – |
| Tally | – | – | 9 Pin | – | 25 Pin, LAN (PTZ Only) | – | 25 Pin, LAN (PTZ Only) | 25 Pin, LAN (PTZ Only) | 25 Pin, LAN (PTZ Only) |
